ELECTRIC FAN-AIR CUSHION
A lifesaving equipment is inflated with air generated from an electric fan, is also used to rescue the persons evacuating from a high-rise buildings in the event of fire or disastrous situation.
Material
Made of 100% Polyester, fire resistance, waterproof, highly tearing resistance,
and made with double seam structure inside cushion.
• Safe rescue from 5th floor to 20th floor of the building.
• Intuitive and quick assembly.
• Easy to carry with a comfortable handle.
Classification
ISO9001:2015 ISO14001:2015 EN ISO6941 DIN 53354:1981 DIN EN 20811 DIN EN ISO 13938-1:999 BS5438 DIN 14151-3
Rescue air mat equipment shockproof comparative table
1. Relative standard : DIN 1415~3
2. Comparison targets :
(1) Ground (without equipment) (2) Sponge (3) Life saving mat (4) Safety air mat (under 15 m)
3. Test date : 19, April 2017
4. Test dummy : 75 kg (Based on DIN 14151~3)
5. Test height : 16m Test tower (Based on DIN 14151~3)
* Used “g” unit of measure in this test, it is measure of acceleration of gravity by DIN 14151~4 {g: 9.81m/s²} it is different with {kg.m/s}
* Conversion table : 0.01 (v) = 1 (g) {Impulse sensor : Apply with SAE-J211}
Main Body
Composed of a canvas bag that captures air generated from an electric fan with top and bottom air layers inside.
Main BodyComposed of a canvas bag that captures air generated from an electric fan with top and bottom air layers inside.
Electric Fan
An electric equipment that inflates the mat with air. (220V, 50~60 Hz)
Electric FanAn electric equipment that inflates the mat with air. (220V, 50~60 Hz)
Ventilation Window
Two different types of windows discharge air from the mat in order to cushion the impact of an evacuators at the moment of falling on the mat.
Ventilation WindowTwo different types of windows discharge air from the mat in order to cushion the impact of an evacuators at the moment of falling on the mat.
Air Inlet
The inlet connects the main body with the electric fan.
Air InletThe inlet connects the main body with the electric fan.
SPECIFICATION
Model | SDF-50 | SDF-70 | SDF-100 | SDF-150 | SDF-200 |
Chamber | Two chambers | ||||
Size meter | 4.0 x 5.0 x 2.5 | 4.5 x 6.0 x 2.5 | 5.0 x 7.0 x 2.5 | 6.0 x 8.0 x 3.0 | 7.0 x 10.0 x 3.0 |
Allowable | under 15meters | 21m | 30m | 45m | 60m |
Height | |||||
Fan Power | 1/2HP | 1/2HP | 1/2HP | 1/2HP | 1/2HP |
Fan Power Supply | AC220V | AC220V | AC220V | AC220V | AC220V |
Fan required | 0.75Kw x 1 | 0.75Kw x 1 | 0.40Kw x 2 | 0.40Kw x 2 | 0.75Kw x 2 |
Installation | 75 sec. | 75 sec. | 80 sec. | 90 sec. | 100 sec. |
Re-inflating | 30 sec. | 30 sec. | 40 sec. | 40 sec. | 45 sec. |
Weight (without fan) | 70.0 kg | 82.0 kg | 95.0 kg | 127.0 kg | 155.0 kg |
ELECTRIC FAN SPECIFICATION
Model | Source | Hz | Power Input (w) | RPM | Motor Output (kw) | Air Volume | kg | |
CMM | CFM | |||||||
DTV-300 | AC220V | 50/60 | 450 | 2850 | 0.4 | 53 | 1870 | 14.0 |
600 | 3300 | 0.4 | 61 | 2155 | ||||
DTV-350 | AC220V | 50/60 | 925 | 2900 | 0.75 | 105 | 3710 | 16.5 |
960 | 3400 | 0.75 | 125 | 4415 | ||||
DTV-500 | AC220V | 470 | 3.4 | 710 | 1445 | 4,945 | 36 | 32.0 |
4.9 | 1,060 | 1680 | 5,650 | 48 | ||||
ELECTRIC FAN
Feature.
Easy for moving and treatment. Easy for DUCT installation.
High capability, High Efficiency, small and light.
Any usage is possible to blow and exhaust as per workspace.
Durable and flexible duct. Easy for installation.
Continuous operating with powerful MOTOR
Various usage and extent. Prevent Suffocation accident and improving the work place.
Place to use
Extracting gas during sewerage & underground cable construction, shipbuilding, piping and bridge construction.
Ventilating of Manhole, Tank or inspection/repairing of boiler.
Drying or Ventilating during painting. Ventilating of working place with dust.
Ventilating for underground and extracting smoke and gas.
HOW TO FOLD
Precautions
One person should make a jump at a time.
The next evacuator should try a jump after the mat recovers its original shape.
Installation is available only at the places with the supply of commercial or emergency electricity.
The safety air cushion should be installed at the location where the evacuator could fall on the center of the mat.(Especially, choose the location carefully at night due to bad visibility of an evacuator.)
